Measurement Guide

Proper Fit · Correct Part

Getting the best fit for your rubber tracks requires correct measurement. Not sure where to start? We've got you covered.

Important!

All measurements are in millimeters.

1 inch = 25.4 millimeters

Step 1

Machine Identification

Make _________________ Model __________________ Year______

Example: Bobcat, T190, 2008

Step 2

Track Sizing and Measurement

Check your existing track to see if the size is stamped into the rim of the track. If you can't ﬁnd a track size stamped into the rubber then you can take the three simple measurements listed below that will determine which replacement track you need.

Width(W) x Pitch(P) x Links(L)

Example: 450mm X 86mm X 55

Width: Measure the width of your track.
Pitch: Measure the distance from center of one link to center of the next link.
Links: Count the number of links or lugs all the way around the track.

Step 3

Guiding System Measurement

To measure the guiding system look for the trough running lengthwise down the inside of the track.

Width(A) x Width(B) x Height(C)

Example: 20mm X 20mm X 20mm

Guiding System Width, Width, and Height Drawing

Guiding System Width, Width, and Height Image

Width (A): Measure the distance from the bottom of the outside of the lug to the bottom.
Width (B): Measure the distance from the bottom of the inside of the lug to the bottom of the inside of the lug across from it. (IGB -Inside Guide Bottom).
Height (C): Measure the inside height of the lug.

Step 4

Roller Type

Please select the correct roller type of your track.
